産品主要特性
1.較好的剝離強度
2.優良耐化學性
3.優異的電性能和絕緣性
4.不含鹵素
産品規格
|
白色單面板ASP-BS系列 透明單面板ASP-LS系列 |
白色雙面板ASP-BD系列 透明雙面板ASP-LD系列 |
||
PET(um) |
12.5~75 |
|
12.5~75 |
|
Adhesive (um) |
10~35 |
10~35 |
||
Copper(um) |
12~35(RA&ED) |
12~35(RA&ED) |
産品性能表
Test Item |
Condition |
Property |
Standard |
Test method |
|||
ASP-B |
ASP-L |
||||||
Peel Strength |
Normal(Kgf/cm) |
90° |
0.9 |
1.0 |
≧0.7 |
IPC-TM-650 2.4.9 |
|
Chemical Resistance(Drop %) |
IPA |
Dipping /10min |
3.5 |
3.2 |
≦20 |
IPC-TM-650 2.3.2 |
|
NaOH |
4.7 |
4.1 |
|||||
HCL |
7.3 |
7.8 |
|||||
Moisture Absorption(%) |
D-24/23 |
1.3 |
1.3 |
≦2.0 |
IPC-TM-650 2.6.2 |
||
Solder Float Resistance |
230℃/30sec |
OK |
OK |
230℃/30sec |
IPC-TM-650 2.4.13 |
||
Dimensional Stability(%) |
MD |
Method B |
-0.02 |
-0.01 |
±0.15 |
IPC-TM-650 2.2.4 |
|
TD |
0.03 |
0.03 |
|||||
Volume Resistance(Ω-cm) |
C-96/35/90 |
1.5×1016 |
2.9×1016 |
≧1012 |
IPC-TM-650 2.5.17 |
||
Surface Resistance(Ω) |
1.7×1014 |
2.2×1014 |
≧1011 |
||||
Insulation Resistance(Ω) |
2.1×1011 |
3.5×1011 |
≧109 |
IPC-TM-650 2.6.3.2 |
|||
Dielectric Constant (1GHZ) |
C-24/23/50 |
3.6 |
3.4 |
≦4.0 |
IPC-TM-650 2.5.5.3 |
||
Dissipation Factor (1GHZ) |
0.022 |
0.020 |
≦0.04 |
儲存條件
包裝良好:溫度30℃以下,濕度70%以下儲存一年。 Packaging: Below 30℃ and 70%RH for one year.
